青島國際會展中心二期工程點支式索桁架玻璃幕墻設計與施工

　　摘 要：本文首先對青島國際會展中心二期工程中的索支承玻璃幕墻方案進行了詳細介紹，然后結合該工程，對其中采用的自平衡索桁架結構和魚腹式索桁架結構，這兩種點支式玻璃幕墻結構中較為先進支承結構形式 的工程應用展開了具體的討論，包括材料選用、結構設計、節點設計及構造、結構檢測、玻璃幕墻檢測和結構施工等，涵蓋了這兩種結構形式工程應用的各個方面，為今后這類工程結構的設計和施工提供了依據。

　　關鍵詞：索結構；點支式玻璃幕墻；鋼結構
　　Abstract：In this paper, the blue print of cable supported glass curtain wall was detailed introduced. And then with this project, the detailed engineering application technologies of the self-balance cable truss and fish belly shaped like cable truss, which are advanced structures in dot point supported glazing with the character of lightness and transparency, were discussed, including the material, structural design, joint forms and conformation, structure test, glass curtain wall test and constructions, almost all fields of these kinds of cable structures were involved. And all of these work have brought the base for the engineering design and constructions for these two kinds of cable structures in the future.
　　Key Words：Cable structure；Dot point supported glazing；Steel structure
